Propulsion system Hobbywing CM-H8M-8108-85KV-D30-CW

Product detailed description

Propulsion system Hobbywing CM-H8M-8108-85KV-D30-CW

The Hobbywing CM-H8M-8108-85KV-D30-CCW brushless power system is an industrial-grade solution designed to deliver a maximum thrust of 7.4 kg per axis and a recommended load of 2.5–3.5 kg. It features an IP45 waterproof protection level and is ideal for professional aerial photography, police operations, rescue missions, and other demanding applications.

Features:

- Rotates clockwise (CW).
- Direct drive motor with FOC ESC.
- Supports CAN communication.
- Dual redundancy with digital throttle and PWM control.
- Built-in protections against overload, overheating, and rotor lock.
- Easy installation and reliable connections.

*Please note, props sold separately.

Specifications:

- Recommended Load: 2.5-3.5 kg
- Max Thrust: 7.4 kg
- Motor KV: 85 KV
- ESC Continuous Current: 20 A
- ESC Instantaneous Current: 60 A (up to 3 seconds)
- Power Supply: 12-14S LiPo (Max 63V)
- Protection Level: IP45
- Operating Temperature: -20°C to +50°C
- Throttle Range: 1100-1940 μs
- Motor Dimensions: Φ87 × 34.7 mm
- Propeller Dimensions: 30 × 9.8 inch

Package Includes:
1x Propulsion system Hobbywing CM-H8M-8108-85KV-D30-CW
