Motor SunnySky V3 X2820 570KV

Product detailed description

Motor SunnySky V3 X2820 570KV

The SunnySky V3 X2820 570KV motor is engineered for optimal performance in high-thrust applications. With its 570KV rating, this motor provides exceptional power and efficiency. The robust design features a smooth 5 mm shaft and is built with a hollow-cased structure for superior heat dissipation and reduced weight.

Specifications:

Model: X2820
KV: 570
Max Thrust: 4000 g
Voltage: 22.2 V
Nominal Current: 2.6 A
Peak Current: 60 A
Idle Current: 0,83 A
Max Continuous Current: 53 A
Max Continuous Power: 1325 W
Shaft: Smooth Shaft
Shaft Diameter: 5 mm
Resistance: 53 mΩ
Configuration: 12N14P
Wire Length: 100 mm
Motor Mounting: 19x25 mm; 44x44 mm
Recommended Propellers: 12x65", 12x80", 13x70"
Dimensions: 35x35x61 mm
Weight: 146 g

Package Includes:
1x Motor SunnySky V3 X2820 570KV
