Goggles HDZero BoxPro

Product detailed description

HDZero BoxPro FPV Goggle - The Ultimate Goggle for Digital, Analog, and HDMI Video

The HDZero BoxPro is a high-performance FPV goggle designed for pilots seeking smooth, low-latency visuals at an incredible value. Supporting HDZero digital, analog, and HDMI input, it features a 100Hz, 1800 nits LCD display for an ultra-bright and fluid viewing experience.

Unlike other goggles, the BoxPro boasts a 100Hz refresh rate screen and a 100Hz HDMI input, delivering exceptional responsiveness with minimal latency. Equipped with a built-in high-sensitivity analog receiver and four antennas—two integrated high-gain patch antennas and two included linear SMA antennas—this goggle offers excellent reception right out of the box. Whether you fly analog or digital, the BoxPro delivers flagship performance at a fraction of the cost.

Specifications:

Display: 100Hz, 1800 nits ultra-bright LCD
Field of View (FOV): 56°
Latency:
- HDMI input: 1ms
- Analog camera: 3ms
- HDZero camera: 4ms
Video Support: HDZero digital, analog, mini HDMI input & output
Analog Receiver: Built-in high-sensitivity receiver
Antenna Setup:
- 2 inbuilt high-gain patch antennas
- 2 included linear 5.8GHz SMA antennas
DVR & Recording:
- Formats: H.265 (HDZero, analog, HDMI)
- Resolutions: 1280x720p60, 1280x720p90, 1280x720p100, 1920x1080p60
- Audio: Multiple sources (built-in mic, line-in, AV-in)
- Recording modes: Automatic & manual
Power Input: 2S-6S battery via XT60 connector (battery not included)
Cooling System: Adjustable fan speed for internal cooling and anti-fog prevention
Software: Open-source, Linux-based platform for customization

Package Includes:
1x HDZero BoxPro Goggle
2x Linear 5.8GHz SMA Antennas (with 2 inbuilt high-gain patch antennas)
1x Foam Face Pad
1x Adjustable Head Strap with Battery Pocket
1x 1200mm XT60 Power Cable
1x Durable Canvas Goggle Bag
1x Lens Cleaning Cloth
