Frame GEPRC GEP-LC75V3 for Crocodile75 V3 Drone
Code: GP105910Related products
Product detailed description
GEP-LC75V3 GEP-LC75 V3 is a long-range frame, that uses an H-shaped structure design and adds protective side panels to the fuselage to protect the electronic control system from dust pollution. The arm is made of a 6mm thick carbon fiber plate to improve flight stability. The fuselage structure optimizes the strength of the main stress points to ensure strong crashworthiness. Feature: - The fuselage adds protective side panels to save the electronic control system from sand and dust pollution. - Perfect match for 7-inch or 7.5-inch propellers. - The Crocodile75 V3 frame has a lengthier fuselage, can be mounted with Lipo 6S 3300mah-4500mah or Lion 6S 6000mah battery for flight. Specification: Model: GEP-LC75 V3 Size: 7.5 inch Wheelbase: 342mm Top plate: 2.5mm Bottom plate: 3.0mm Arm plate: 6.0mm FC mounting hole: 30.5x30.5mm VTX mounting hole: 20x20mm / 25.5x25.5mm Motor mounting hole: 16x16mm / 19x19mm Camera mounting hole: 19-20mm Recommended propeller size: 7-7.5inch Weight: 266g
Additional parameters
| Category: | FPV Frames |
|---|---|
| Warranty: | 2 years |
| Material: | Carbon fiber |
| Camera Mounting: | Micro (19 mm) |
| Size: | 7 inch |
| Wheelbase: | 342 mm |
| Drone Type: | Long Range |
| The item has been sold out… | |
