FPV Drone iFlight Nazgul Evoque F6D V2 O4 Pro 6S BNF ELRS 2.4G GPS

Product detailed description

FPV Drone iFlight Nazgul Evoque F6D V2 O4 Pro 6S BNF ELRS 2.4G GPS

The iFlight Nazgul Evoque F6D V2 O4 Pro is a high-performance 6-inch Bind-And-Fly FPV drone designed for cinematic long-range flights and aggressive freestyle performance. Equipped with the DJI O4 Air Unit Pro and pre-installed ELRS 2.4GHz receiver, it delivers ultra-low latency control, stable long-range radio performance, and crystal-clear HD video transmission. Its durable deadcat frame, integrated GPS system, and efficient XING2 motors provide smooth cinematic footage, strong flight power, and reliable operation for demanding FPV pilots.

Features:
- Equipped with DJI O4 Air Unit Pro for ultra-low latency HD digital video transmission and cinematic 4K recording capability
- Deadcat frame design ensures props are out of view for clean, professional aerial footage
- Pre-installed GPS module enhances flight safety with position hold, return-to-home, and improved navigation stability
- High-efficiency XING2 motors provide smooth power delivery, strong thrust, and durable performance
- Optimized aerodynamic frame design protects electronics from dirt, moisture, and crash debris while maintaining cooling airflow
- Long-range HD transmission with stable signal performance for confident exploration flights
- Integrated anti-spark battery protection system reduces connector wear and improves electrical safety
- Lightweight yet durable construction balances agility, endurance, and crash resistance
- Designed for cinematic and freestyle flying with stable vibration control and smooth flight behavior
- Bind-and-Fly setup with no receiver included, allowing direct use with DJI remote controller systems
- Dual-antenna system improves signal reliability and transmission stability
- Pre-installed ELRS 2.4GHz receiver provides reliable low-latency control signal and excellent long-range performance

Specification:
Product Name: Evoque F6 V2 O4 HD
Geometry: Deadcat (DC)
FC: BLITZ Mini F722 Flight Controller
ESC: BLITZ Mini E55 4-IN-1 2-6S 55A ESC
Video Transmission: DJI O4 Air Unit Pro
Frame wheelbase: 262±2mm (DeadCat)
Motor: XING2 2506 1500KV motors
Prop: HQ 6x2.5x3 propellers
Weight: 485±5g(DeadCat)
Takeoff Weight: Approx.710±5g (With 6S 1480mAh)
Dimensions: 209x162x36±2mm
Diagonal Distance: 120 mm
Max Speed: 180 km/h
Maximum Takeoff Altitude: 3200 m
Max Hover Time: Approx. 8.5 min (No load With 6S 1480mAh)
Max Flight Distance: 5 km
Operating Temperature Range: -10° to 40° C (14° to 104° F)
Antennas: Dual Antennas
GNSS: GPS+SBAS+Galileo+QZSS+Glonass
Receiver option: iFlight ELRS 2.4GHz
Compatibility: DJI Goggles 3 / DJI Goggles N3 + DJI FPV Remote Controller 3; DJI Goggles 2 / DJI Goggles Integra + DJI FPV remote control 2

Note: The BNF does not include the remote control, goggles, GoPro, battery, or charger, which need to be purchased separately for compatible use

Video Transmission
Product Name: DJI O4 Air Unit Pro
Image Sensor: 1/1.3-inch
Lens: FOV: 155°
ISO: 100-25600
Video Resolution: 1080p/100fps H.265
Video Format: MP4, Max Video Bitrate: 130Mbps
Color Mode: Normal Mode/D-Log M
Stabilization: RockSteady 3.0+ ; Stabilization function off (When RockSteady is enabled, the shooting angle only supports standard.)
Live View Quality: 1080P@100fps
Operating Frequency: 5.170-5.250 GHz  & 5.725-5.850 GHz
Transmitter Power (EIRP): 5.1GHz＜23dBm(CE)/5.8GHz＜33dBm(FCC)/＜14dBm(CE)/＜30dBm(SRRC))
Max Video Transmission Range: With DJI Goggles 3/DJI Goggles N3: 15 km (FCC), 8 km (CE), 8 km (SRRC)
Communication Bandwidth: Max 60 MHz
Antenna: Dual antennas
Built-in Storage: 4GB
Supported SD cards: microSD (up to 512GB)
Operating Temperature: -10° to 40° C
Weight: Air Unit (camera module included): Approx. 32 g
Dimensions: Transmission Module: 33.5x33.5x13 mm

Package Include:
1x Evoque F6 6S O4 HD BNF
2x Antennas
1x Battery pad
2x Propeller (Pairs)
2x Battery strap
