FPV Drone iFlight CineFlow 5 O4 Pro 6S BNF ELRS Dualband Diversity GPS Waterproof

Product detailed description

FPV Drone iFlight CineFlow 5 O4 Pro 6S BNF ELRS Dualband Diversity GPS Waterproof

The iFlight CineFlow 5 O4 Pro 6S BNF ELRS Dualband Diversity is a high-performance cinematic FPV drone designed for freestyle, long-range flights, and professional video capture. Featuring the DJI O4 Air Unit Pro, it delivers stunning 1080p/100fps footage with an ultra-wide field of view, while the waterproof sealed design ensures reliable operation in various conditions.

Equipped with a built-in ELRS 100mW dualband diversity receiver (868/915/2.4GHz), the drone provides exceptional signal stability by utilizing multiple frequency bands and antennas, automatically maintaining the strongest link for improved range, better penetration, and reduced signal loss.

Features:
- Innovative H-frame design eliminates props in view for clean cinematic footage
- Waterproof sealed structure protects internal components from splashes and light water exposure
- Quick-release side panels ensure easy maintenance and clean cable management
- DJI O4 Air Unit Pro delivers ultra-wide 155° FOV and high-quality 1080p/100fps video transmission
- Powerful performance with low hover throttle for enhanced maneuverability and control
- High-end BLITZ F7 FC and E55R ESC provide stable and responsive flight under heavy loads
- Built-in high-precision GPS module improves safety and reduces flyaway risk
- Rear battery plug with anti-spark filter enhances weight balance and protects circuitry
- Front-mounted air unit improves cooling efficiency and system longevity
- Integrated action camera mount for clean and functional cinematic setup
- ELRS 100mW Dualband Diversity RX 868/915MHz as well as 2400MHz receiver have outstanding performance and long range capabilities

Specifications:
Product Name: CineFlow 5 O4 HD BNF
Geometry: H-shaped
FC: BLITZ Mini F7 Flight Controller
ESC: BLITZ Mini E55R 4-IN-1 ESC
Video Transmission: DJI O4 Air Unit Pro
Frame wheelbase: 222mm
Motor: XING2 2207 2050KV motors
Prop: Nazgul F5 propellers
Dimensions: 213x209x42mm
Weight: 499±5g
Takeoff Weight: Approx. 741±5g (With 6S 1400mAh Battery)
Max Speed: 190 km/h
Maximum Takeoff Altitude: 7000 m
Max Hover Time: Approx. 12 min
Max Flight Distance: 5 km
Operating Temperature Range: -20° to 40° C
Antennas: Dual Antennas
GNSS： GPS+SBAS+Galileo+QZSS+Glonass
Receiver: iFlight ELRS 100mW Dualband Diversity RX (868/915/2.4GHz)

Video Transmission:
Product Name: DJI O4 Air Unit Pro
Image Sensor: 1/1.3-inch
Lens: FOV: 155°
ISO: 100-25600
Video Resolution: 1080p/100fps H.265
Video Format: MP4, Max Video Bitrate: 130Mbps
Color Mode: Normal Mode/D-Log M
Stabilization: RockSteady 3.0+ ; Stabilization function off (When RockSteady is enabled, the shooting angle only supports standard.)
Live View Quality: 1080P@100fps
Operating Frequency: 5.170-5.250 GHz  & 5.725-5.850 GHz
Transmitter Power (EIRP): 5.1GHz＜23dBm(CE)/5.8GHz＜33dBm(FCC)/＜14dBm(CE)/＜30dBm(SRRC))
Max Video Transmission Range: With DJI Goggles 3/DJI Goggles N3: 15 km (FCC), 8 km (CE), 8 km (SRRC)
Communication Bandwidth: Max 60 MHz
Antenna: Dual antennas
Built-in Storage: 4GB
Supported SD cards: microSD (up to 512GB)
Operating Temperature: -10° to 40° C
Weight: Air Unit (camera module included): Approx. 32 g
Dimensions: Transmission Module: 33.5x33.5x13 mm

Package includes:
1x FPV Drone iFlight CineFlow 5 O4 Pro 6S BNF ELRS Dualband Diversity GPS Waterproof
2x Antennas
1x Battery pad
2x propeller(Pairs)
2x Battery strap
