Frame iFlight iH3 O3
Code: FQ14091Related products
Product detailed description
iH3 O3 Frame Kit Specifications: Product Name: iH3 O3 3.5inch Frame Kit Geometry: H-shaped Frame wheelbase: 168 mm Frame Dimensions (L×W×H): 135×100×40 mm (From Canopy) Arm Thickness: 3mm Bottom Plate Thickness: 3mm Top Plate Thickness: 2mm Max Flight Stack Height: 19mm Max VTX Height: 22mm Motor Mounting: 9x9mm/12x12mm VTX Mounting: 20*20 Φ2mm/ 25.5*25.5 Φ1.6mm Weight: 110 grams Packing List: 1 x iH3 Frame 1 x Screw Bag 1 x TPU Set 1 x Battery anti-slip mat 1 x Battery strap
Additional parameters
| Category: | FPV Frames |
|---|---|
| Material: | Carbon fiber |
| Size: | 3.5 inch |
| Motor Size: | 1504 |
| Wheelbase: | 168mm |
| Drone Type: | Racing |
| The item has been sold out… | |
