FPV Drone iFlight Defender 20 Lite O4 BNF ELRS 2.4GHz SMD Antenna

Product detailed description

FPV Drone Defender 20 Lite O4 BNF ELRS 2.4GHz SMD Antenna

The Defender 20 Lite O4 by iFlight is a palm-sized 2-inch cinewhoop drone equipped with DJI’s O4 Air Unit for stunning 4K stabilized video. Designed for portability and quiet operation, it excels in both indoor and tight outdoor environments. With a quick-release prop guard system, built-in plug-in battery with auto power-on, and up to 7.5 minutes of flight time, it's ideal for creators on the move. The modular podded camera mount minimizes vibrations, enabling clean, jello-free footage with Gyroflow support. Ready to fly with ELRS 2.4GHz receiver and SMD antenna, this drone brings cinematic FPV to your pocket.

Features:

- Built-in DJI O4 Air Unit 4K recording in a lightweight 2-inch frame with stabilization and Gyroflow support. With large storage capacity and low-latency, long-range video transmission, it ensures smooth first-person view footage for a more immersive flight experience.
- Designed with a compact palm-sized frame, this device easily fits in a pocket for convenient portability. Its ultra-lightweight build and low flight noise make it ideal for undisturbed indoor flying, while its versatility allows it to navigate complex and narrow environments.
- With hover throttle as low as 25%, this device provides ample power for effortless flight. It offers up to 7.5 minutes of flight time, extending creative possibilities and ensuring a smooth and enjoyable flying experience.
- The prop guard enhances safety by preventing accidents during crashes, while its quick-release design allows for seamless switching. Removing the prop guard increases agility, enabling dynamic freestyle maneuvers for more advanced flying techniques.

Specifications:

Product Name: Defender 20 Lite O4 2S HD
Flight Electronics: F411 AIO
Video Transmission: DJI O4 Air Unit
Frame wheelbase: 87mm
Motor: Defender 16 1103 14000KVmotors
Prop: Defender 20 Lite 2020*3 props
Weight: 69±3g
Takeoff Weight: Approx. 108±3g (With 600mAh Battery)
Dimensions (L×W×H): 125*125*44.5mm
Max Speed: 75km/h (Manual Mode)
Maximum Takeoff Altitude: 2000 m
Max Hover Time: Approx. 6.5-7.5 mins(with 2S 600mAh battery)
Max Wind Speed Resistance: Level 3
Operating Temperature Range: -10° to 40° C
Antennas: Single Antenna

Video Transmission:

Product Name: DJI O4 Air Unit
Image Sensor: 1/2-inch CMOS Sensor
Lens: FOV: 117.6°
ISO: 100-6400 (Auto); 100-12800 (Manual)
Video Resolution: 1080p/100fps H.265
Video Format: MP4
Max Video Bitrate: 100 Mbps
Color Mode: Normal Mode
Live View Quality: 1080P@30/50/60/100fps
Operating Frequency: 5.170-5.250 GHz; 5.725-5.850 GHz
Transmitter Power (EIRP): .1 GHz: <23 dBm (CE); 5.8 GHz:<30 dBm (FCC)<14 dBm (CE)< 30 dBm (SRRC)
Max Video Transmission Range(With DJI Goggles 3/DJI Goggles N3): 10 km (FCC), 6 km (CE), 6 km (SRRC)
Communication Bandwidth: Max 60 MHz
Antenna: Single antenna
Built-in Storage: 23GB
Supported SD cards: Not supported
Operating Temperature: -10° to 40° C
Weight: Air Unit (camera module included): Approx. 8.2 g
Dimensions: Transmission Module: 30×30× 6 mm (L×W×H)

Package includes:

1 x Defender 20 Lite O4 HD BNF
1 x Defender 20 Lite 2S 600mAh Battery
1 x Charging Adapter
1 x Propeller Removal Tool
1 x Defender 20 Carrying Case
