FC Pilotix H743 BMI270

Product detailed description

Pilotix H743 BMI270 Flight Controller - Product Introduction

The Pilotix H743 BMI270 is a high-performance flight controller designed for professional and hobbyist drone pilots alike. Built with precision and versatility in mind, this flight controller is powered by the STM32H743VIH6 controller and supports advanced features to enhance flight stability and control.

Key Specifications:

• Controller: STM32H743VIH6
• Gyroscope: Dual BMI270 and MPU 6000 for precise and reliable motion tracking
• Barometer Options: BMP280, DPS310, or MS5611 for accurate altitude measurements
• Black Box: 128MB onboard memory for flight data logging
• Motor Outputs: Supports up to 10 channels for multi-rotor setups
• Servo Outputs: 2 channels for additional control functions
• Universal Serial Ports: 8 channels for flexible peripheral connections
• Power Input: Supports 3S to 6S LiPo batteries
• Power Output: 5V/25A and 9V/3A outputs for reliable power distribution to connected components
• Weight: Lightweight at only 8.8g, ideal for compact and lightweight drones
• Dimensions: 37mm x 37mm for easy integration
• Mounting Hole Spacing: 30.5mm x 30.5mm, standard for most frames
