Frame iFlight Chimera6 FPV LR
Code: FQ09940Related products
Product detailed description
Chimera6 FPV LR Frame Kit Super-efficient 6-inch frame for long-range flights and mounting a large battery to have ample flight time for exploring any airspace! Specifications: Model: Chimera 6 Frame type: DeadCat Wheelbase: 266.7mm Main body dimension: 200.1*168.3mm Bottom to top distance: 28mm Arm thickness: 5mm Bottom plate thickness: 2mm Top plate thickness: 2mm Middle Plate thickness: 3mm TPU Camera plate FC: 30.5*30.5mm/20*20mm FPV Cam: 19mm Micro / 20mm Recommend Motor: 22XX / 23XX Mounting pattern: 16*16mm Packing List: 1 x Chimera6 FPV LR Frame Kit 2 x battery straps 1 x TPU parts
Additional parameters
| Category: | FPV Frames |
|---|---|
| Material: | Carbon fiber |
| Camera Mounting: | Micro (19mm) |
| Size: | 6 inch |
| Motor Size: | 2306 |
| Wheelbase: | 266.7mm |
| Drone Type: | Long Range |
| The item has been sold out… | |
